TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
28 t - 50 t |
|
Service weight ² |
2 750 kg |
|
Oil flow |
180 l/min - 200 l/min |
|
Max. Closing Force |
9 t |
|
Operating pressure |
350 bar |
|
Oil flow, rotation |
30 l/min - 35 l/min |
|
Max operating pressure, rotation |
170 bar |
|
Jaw opening, max |
2 270 mm |
|
Grapple width |
1 200 mm |
|
Loading volumen |
0,92 m³ |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
2.Attachment with average-sized adapter plate.
