TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
2 t - 5 t |
|
Service weight ² |
290 kg |
|
Oil flow |
25 l/min - 35 l/min |
|
Max. Closing Force |
2 t |
|
Operating pressure |
300 bar |
|
Oil flow, rotation |
10 l/min - 15 l/min |
|
Max operating pressure, rotation |
170 bar |
|
Jaw opening, max |
1 187 mm |
|
Grapple width |
500 mm |
|
Loading volumen |
0,11 m³ |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
2.Attachment with average-sized adapter plate.
