TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
45 t - 100 t |
|
Service weight ² |
5 300 kg |
|
Oil flow |
280 l/min - 300 l/min |
|
Max. Closing Force |
13 t |
|
Operating pressure |
350 bar |
|
Oil flow, rotation |
50 l/min - 60 l/min |
|
Max operating pressure, rotation |
210 bar |
|
Jaw opening, max |
3 000 mm |
|
Grapple width |
1 500 mm |
|
Loading volumen |
1,6 m³ |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
2.Attachment with average-sized adapter plate.
