TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
1,2 t - 3 t |
|
Service weight ² |
175 kg |
|
Oil flow |
15 l/min - 25 l/min |
|
Max. Closing Force |
1,5 t |
|
Operating pressure |
300 bar |
|
Oil flow, rotation |
5 l/min - 10 l/min |
|
Max operating pressure, rotation |
170 bar |
|
Jaw opening, max |
900 mm |
|
Grapple width |
450 mm |
|
Loading volumen |
0,05 m³ |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
2.Attachment with average-sized adapter plate.
