TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
10 t - 16 t |
|
Service weight ² |
825 kg |
|
Oil flow |
70 l/min - 100 l/min |
|
Max. Closing Force |
3,8 t |
|
Operating pressure |
350 bar |
|
Oil flow, rotation |
20 l/min - 25 l/min |
|
Max operating pressure, rotation |
170 bar |
|
Jaw opening, max |
1 791 mm |
|
Grapple width |
800 mm |
|
Loading volumen |
0,35 m³ |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
2.Attachment with average-sized adapter plate.
