TECHNICAL SPECIFICATIONS

Service weight ²

 3 100 kg

Oil flow

 210 l/min - 270 l/min

Operating pressure

 160 bar - 180 bar

Impact rate

 280 blows/min - 560 blows/min

Working tool diameter

 165 mm

Working length of tool

 745 mm

Carrier weight class ¹

 32 t - 52 t

Hydraulic input power, max

 81 kW

Sound power level, guaranteed ³

 120 dB(A)




  1. Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
  2. Attachment with standard working tool & average-sized adapter plate.
  3. EN ISO 3744 in accordance with directive 2000/14/EC
