TECHNICAL SPECIFICATIONS
|
Service weight ² |
1 200 kg |
|
Oil flow |
100 l/min - 140 l/min |
|
Operating pressure |
160 bar - 180 bar |
|
Impact rate |
340 blows/min - 680 blows/min |
|
Working tool diameter |
120 mm |
|
Working length of tool |
610 mm |
|
Carrier weight class ¹ |
15 t - 26 t |
|
Hydraulic input power, max |
42 kW |
|
Sound power level, guaranteed ³ |
120 dB(A) |
- Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
- Attachment with standard working tool & average-sized adapter plate.
- EN ISO 3744 in accordance with directive 2000/14/EC
