TECHNICAL SPECIFICATIONS
|
Service weight ² |
300 kg |
|
Oil flow |
50 l/min - 80 l/min |
|
Operating pressure |
100 bar - 150 bar |
|
Impact rate |
600 blows/min - 1 400 blows/min |
|
Working tool diameter |
80 mm |
|
Working length of tool |
440 mm |
|
Carrier weight class ¹ |
4,5 t - 9 t |
|
Hydraulic input power, max |
20 kW |
|
Sound power level, guaranteed ³ |
119 dB(A) |
- Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrer manufacturer prior to attachment.
- Attachment with standard working tool & average-sized adapter plate.
- EN ISO 3744 in accordance with directive 2000/14/EC
