TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
32 t - 50 t |
|
Service weight ² |
3 700 kg |
|
Crushing force, jaw tip |
109 t |
|
Oil flow |
220 l/min - 350 l/min |
|
Operating pressure |
350 bar |
|
Closing cycle |
2,8 Seconds |
|
Opening cycle |
3 Seconds |
ROTATION DEVICE
|
Oil flow, rotation |
35 l/min - 50 l/min |
|
Max. operating pressure |
170 bar |
DIMENSIONS
|
Jaw opening, max |
1 000 mm |
|
Jaw depth |
765 mm |
|
Blade length |
525 mm |
VERSION WITH STEEL CUTTING JAW
|
Service weight ² |
3 400 kg |
|
Jaw opening |
440 mm |
|
Depth |
625 mm |
|
Blade size |
525 mm |
|
Cutting force, jaw tip |
141 t |
