TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
25 t - 40 t |
|
Service weight ² |
3 100 kg |
|
Crushing force, jaw tip |
104 t |
|
Oil flow |
150 l/min - 250 l/min |
|
Operating pressure |
350 bar |
|
Closing cycle |
2,9 Seconds |
|
Opening cycle |
3,1 Seconds |
ROTATION DEVICE
|
Oil flow, rotation |
35 l/min - 50 l/min |
|
Max. operating pressure |
170 bar |
DIMENSIONS
|
Jaw opening, max |
870 mm |
|
Jaw depth |
700 mm |
|
Blade length |
350 mm |
VERSION WITH STEEL CUTTING JAW
|
Service weight ² |
2 850 kg |
|
Jaw opening |
400 mm |
|
Depth |
465 mm |
|
Blade size |
380 mm |
|
Cutting force, jaw tip |
145 t |
