TECHNICAL SPECIFICATIONS
|
Carrier weight class ¹ |
20 t - 40 t |
|
Service weight ² |
2 100 kg |
|
Product weight |
1 850 kg |
|
Nominal power |
120 kW |
|
Rotation speed |
75 rpm |
|
Optimum oil flow ³ |
205 l/min - 300 l/min |
|
Max. torque @ 350 bar |
23 400 Nm |
|
Max. cutting force @ 350 bar |
65 000 N |
|
Pick shaft diameter |
30 mm |
|
Number of picks |
48 |
|
Max. oil flow @ 10 bar |
320 l/min |
|
Max. operating pressure |
350 bar |
1.Weights apply to standard carriers only. Any variances must be agreed with Epiroc and/or the carrier manufacturer prior to attachment.
2.Attachment with standard picks & average-sized adapter plate.
3.Various motor variants available per model.
