Technical specifications, metric
|
Model |
|
CB 350 |
CB 750 |
CB 950 |
CB 2500 |
|---|---|---|---|---|---|
|
Carrier weight class* |
t |
2-8 |
7-14 |
12-20 |
20-35 |
|
Service weight** |
kg |
320 |
730 |
940 |
2.600 |
|
Jaw opening, max. |
mm |
380 |
480 |
680 |
1.100 |
|
Jaw depth |
mm |
219 |
269 |
324 |
750 |
|
Blade length |
mm |
90 |
140 |
140 |
240 |
|
Crushing force, jaw tip |
t |
40 |
45 |
55 |
100 |
|
Operating pressure |
bar |
300 |
350 |
350 |
350 |
|
Oil flow |
l/min |
50-90 |
90-180 |
90-180 |
150-250 |
|
Max. operating pressure, rotation |
bar |
170 |
210 |
210 |
170 |
|
Oil flow, rotation |
l/min |
5-10 |
20-25 |
20-25 |
35-50 |
| *Weight apply to standard carriers only. Any variations must be agreed with Epiroc and/or the carrier manufacturer prior to attachment. **Attachment with average-sized adapter plate. | |||||
