Technical specifications
| Model | LPHB | |
|---|---|---|
| Weight | kg (lb) | 20 (44) |
| Service weight (incl 200 mm auger) | kg (lb) | 30.5 (67) |
| Oil flow | l/min (gpm) | 15-40 (3.96-10.75) |
| Working pressure | bar (psi) | 80-140 (1,450-2,030) |
| Max. back pressure | bar (psi) | 50 (725) |
| Revolutions | rpm | 90-240 |
| Auger size diameter | mm (in) | 90-350 (4-14) |
| Torque (at 140 bar) | Nm (ft lb) | 315 (232) |
| Vibration level 3 axes (ISO 28927-5) 20 lpm *1 | m/s² | 7.4 |
| Sound pressure level (ISO 11203) *1 | Lp, r=1 dB(A) | <70 |
| EHTMA class | C/D/E | |
| Part number | 1806 1014 33 | |
| *1 Important: Full details of measurement is available in the Safety and Operating instruction of the product. | ||
Augers
| Diameter mm (in) | 90 (3.54) | 150 (5.9) | 200 (7.87) | 250 (9.84) | 280 (11.02) | 360 (14.17) |
|---|---|---|---|---|---|---|
| Length mm | 870 (34.25) | 870 (34.25) | 870 (34.25) | 870 (34.25) | 870 (34.25) | 870 (34.25) |
| Weight kg | 7 (15.43) | 8.9 (19.62) | 10.5 (23.15) | 15 (33.07) | 17.2 (37.92) | 21 (46.3) |
| Part number | 3378 0050 45 | 3378 0050 46 | 3378 0050 44 | 3378 0050 47 | 3378 0050 49 | 3378 0050 48 |
| Auger extension rod | ||
|---|---|---|
| Weight | kg (lb) | 5 (11.02) |
| Length | mm (in) | 500 (19.69) |
| Part number | 3378 0050 55 | |
